Three Color Pneumatic Pad Printing Machine
Description
The Three Color Pad Printing Machine from Naman Enterprises is a high-performance industrial solution designed for precise, multi-color printing on complex and uneven surfaces. Engineered for accuracy, consistency, and productivity, this machine is ideal for manufacturers requiring sharp, durable, and perfectly aligned three-color prints.
Built with a robust structure and smooth pneumatic operation, the machine ensures excellent color registration and repeatability even during high-volume production. It is widely used across industries such as automotive components, electronics, promotional products, medical devices, electrical parts, toys, and packaging.
This advanced pad printing machine supports printing on materials like plastic, rubber, metal, glass, ceramics, and coated surfaces, making it a versatile choice for modern manufacturing needs. Easy setup, low maintenance, and user-friendly controls make it suitable for both small-scale units and large production lines.
At Naman Enterprises, our three color pad printing machines are manufactured using premium-grade components to deliver long-lasting performance, high print speed, and superior print quality.
Key Features:
Three color precision pad printing in a single cycle
High accuracy color registration system
Pneumatic operation for smooth and stable printing
Suitable for flat, curved, cylindrical, and irregular surfaces
Heavy-duty construction for industrial use
Easy operation and minimal maintenance
Compatible with various inks and substrates
Applications:
Electronic switches & keypads
Automotive parts & accessories
Promotional items & gift articles
Medical and electrical components
Toys, caps, bottles, and packaging products
Specifications
| Model | Euro-85/250tcsu |
|---|---|
| Print Image Size [⌀ mm] | 85 |
| Cliche/Plate Size [mm] | 100 x 250 |
| Print Speed [Max./Hrs] | 540 |
| Doctoring Cup Dia [mm] | 90 |
| No. of Colors | 3 |
| Model Euro-85/250tcsu No. of Colors 3 Doctoring Cup Dia [mm] 90 Print Speed [Max./Hrs] 540 Cliche/Plate Size [mm] 100 x 250 Print Image Size [⌀ mm] 85 Product Height [mm] 400 Power Consumption [W] 50 Control System PLC with HMI Control Voltage 12/24 VDC Drive Electro Pneumatic Operating Pressure[Bar] 6-8 Air Consumption [Lit/min.] | 100 |
| Power Consumption [W] | 50 |
| Control System | PLC with HMI |
| Weight kgs (Approx)[Kgs] | 192 |
| Product Height [mm] | 400 |
| Drive | Electro Pneumatic |
| Power Supply | 230 VAC/50Hz. |
| Operating Pressure[Bar] | 6-8 |
| Control Voltage | 12/24 VDC |
| Dimensions (Approx)[mm] | Length - 860, Width - 680, Height - 1465 |
